| Quantity: | |
|---|---|
XV10
XHNOTION
L/C, T/T, Western Union, Paypal, Money Gram
Ningbo, China
10000 PCS Per Month
BOX AND CARTONS
XV10 Type
DC Solenoid Valve
Directional
DIN
Industrial Usage, Water Industrial Usage, Household Usage
1/4,1/8
12VDC, 24VDC, 110VAC, 220VAC
XHnotion
Bluk Packing or Blister Packing
CE
China
8481804090
Electric
Thread
Pilot Operated
Aluminum
Low Pressure
Pilot Piston Structure
FEATURES
SPECIFICATIONS
GENERAL DATA
| Model | XV10L |
| Operation Type | 3/2 N.C.; 3/2 N.O.; 2/2 N.C. |
| Working Medium | Filtered Air/Inert gases |
| Ambient Temperature | -10~80 ºC |
| Working Pressure | 0-7bar |
| Orifice size | φ0.75mm(P),/φ1.0mm(R) |
| Flow rate at 6 bar(Δp1bar) | 16NL/min(P1→P2), 23NL/min(P2→P3) |
COIL DATA
| Electrical Connector | Vertical type(L)/Horizontal type(M)/Direct line type(G) |
| Stand Voltage | DC24V/12V/6V/3V; AC220V/110V |
| Power | 1W/1.2W double power |
| Insulation | H Class |
| Service life | > 50 million times |
| Duty Cycle | ED 100% |
| Max Operating Frequency | 30Hz |
| Operating Voltage Tolerance | +/- 10% |
| Response Time | Less than 10ms |
| Degree of pretection | IP65 |
ADVANTAGE
1) Valve body is machined by Japan automatic CNC to make sure all the dimensions accurate.
2) Aluminum Surface is polished and hard anodized.
3) To import Germany grease to provide firm less-friction support
4) O-ring is imported from Taiwan.
5) 100% leakage testing under low pressure and high pressure.
6) 1 year quality assurance after shipment.
7) After sales technique support
WORKSHOP SHOW
WHY CHOOSE US?
1) We offer one stop solution. Over 5000 items for you to save efforts and costs.
2)We have molds workshop, die-casting workshop, CNC workshop, plastic injection workshop to make sure each part exactly as the drawing and good function.
3) We will reply you within 24 hours.
4) Whatever quantity you are requesting, we always offer you the best quality.
5)3D drawing, cad drawing service for custom fittings, hose, valve, cylinder.
FAQ
Packing
Transparent plastic bag + white small box + neutral carton + pallet
Custom packaging are available, XHnotion brand packaging are available
Shipping :
Export port: Ningbo or Shanghai, China
Shipping way: by sea, by air, by courier
Delivery time 3 days to 30 days depends on actual orders.
Payment Terms
We accept T/T, L/C, Paypal, western union,etc.
Samples Policy
For regular valve 1 pcs, free samples against your courier account or you pick up from us.
For custom items, we will discuss by email.
Return Policy:
We assure you 1 year policy after shipment. If there is any problem during this period, please contact us for support.
