Burket Series Pilot Operated Solenoid Valve Manufacturer

Model NO.: BP1050Pressure: Ordinary PressureValve Structure: Pilot Membrane StructurePower Supply: DC Solenoid ValveUsage: Flow ControlStandard: DINApplication: Industrial Usage, Water Industrial UsageRegular Voltage: 12VDC, 24VDC, 110VAC, 220VACFluid: Air, Water, Oil, Diesel, Ozone, SteamTrademark: XHnotionTransport Package: Paper BoxSpecification: ROHS, REACH, CEOrigin: ChinaHS Code: 8481804090Media: WaterTemperature: Ordinary TemperatureActuator: ElectricConnection Form: ThreadType: Pilot OperatedMaterial: Brass
  • BP1050


  • L/C, T/T, Western Union, Paypal, Money Gram

  • Ningbo, China

  • 10000 PCS Per Month


  • BP1050

  • Ordinary Pressure

  • Pilot Membrane Structure

  • DC Solenoid Valve

  • Flow Control

  • DIN

  • Industrial Usage, Water Industrial Usage

  • 12VDC, 24VDC, 110VAC, 220VAC

  • Air, Water, Oil, Diesel, Ozone, Steam

  • XHnotion

  • Paper Box


  • China

  • 8481804090

  • Water

  • Ordinary Temperature

  • Electric

  • Thread

  • Pilot Operated

  • Brass

Product Description


1. Compact volume, large flow, widely use

2. Protection class: IP65

3. Seal material: NBR, VITON,  EPDM, SILICONE

4. Body material: brass, stainless steel

5. BD - direct acting, BP - pilot operated, BT - steam valve,  BH - high pressure valve, BD23 - 3 way valve

6. Some models Normally open is available.


MODEL Orifice (mm) Thread (G) Working pressure Medium Temp. Seals material CV value Voltage
Brass SS304
BP1008 BP1008B 10mm G1/4 0.3-10 Bar -10~80ºC Regular seal:NBR   Viton        EPDM 2.3 220VAC     110VAC       24VDC         12VDC            make
Other voltage
as requested
BP1010 BP1010B G3/8
BP1015 BP1015B G1/2
BP1415 BP1415B 14mm G1/2 4.7
BP1420 BP1420B G3/4
BP2020 BP2020B 20mm G3/4 0.3-16 Bar 5.8
BP2025 BP2025B G1
BP4035 BP4035B 40mm G1-1/4 0.5-16 Bar 23.3
BP4040 BP4040B G1-1/2
BP5050 BP5050B 50mm G2 46.7


1) Raw Material conforms to China industry standard, bought from famous factory.

2) Insulation grade: H class, good resistance to high temperature;

3) Machined by CNC to make sure the tolerance as the drawing

4) 100% leakage testing under low pressure and high pressure.

5) All kinds of valve and seals material to meet custom requirement.

6) 1 year quality assurance after shipment.

7) After sales technique support


1) We offer one stop solution. Over 5000 items for you to save efforts and costs.

2)We have molds workshop, die-casting workshop, CNC workshop, plastic injection workshop to make sure each part exactly as the drawing and good function.

3) We will reply you within 24 hours.

4) Whatever quantity you are requesting, we always offer you the best quality.

5)3D drawing, cad drawing service for custom fittings, hose, valve, cylinder


Transparent plastic bag + white small box + neutral carton + pallet
Custom packaging are available, XHnotion brand packaging are available

Shipping :
Export port: Ningbo or Shanghai, China
Shipping way: by sea, by air, by courier
Delivery time 3 days to 30 days depends on actual orders.

Payment Terms
We accept T/T, L/C, Paypal, western union,etc.

Samples Policy
For regular fittings below 20 pcs, free samples against your courier account or you pick up from us.
For custom items, we will discuss by email.

Return Policy:
We assure you 1 year policy after shipment. If there is any problem during this period, please contact us for support.

XHnotion, is a leading manufacturer of pneumatic components and fluid valve in China. Our solenoid valve include below items

Fluid assortment

Water solenoid valve
Air solenoid valve
Diesel solenoid valve
Chemical solenoid valve
We have different solenoid valve for different fluid

Structure assortment

2 way solenoid valve
3 way solenoid valve
4 way solenoid valve
5 way solenoid valve

Acting assortment

Direct acting solenoid valve
Pilot acting solenoid valve

Function assortment

common solenoid valve for air, water
High pressure solenoid valve
Steam solenoid valve
Irrigation solenoid valve
Underwater solenoid valve
Drinking water solenoid valve
Auto drain solenoid valve
Pneumatic angle valve
Pulse jet solenoid valve
Bi-stable solenoid valve
Throttle solenoid valve
Miniature steam solenoid valve

Material assortment

Brass solenoid valve
Plastic solenoid valve
Stainless steel solenoid valve
PTFE solenoid valve
PVC solenoid valve
POM solenoid valve

Meanwhile, we also manufacture below items.

pneumatic fittings, plastic, brass, stainless steel push in fittings

pneumatic quick coupling, air tool kits, air blow gun

pneumatic muffler, silencer, filter

air hose- PU tubes, nylon tube, PE tube, PTFE tubes, etc

air cylinder, air preparation, pneumatic directional valve

modular hose, water push in fitting

Ball valve, brass connector
