ZQDF Series Steam Solenoid Valve

Quantity:
  • Ningbo, China
  • 1000 PCS Per Month
  • L/C, T/T, Western Union, Paypal, Money Gram
  • ZQDF-25
  • Ordinary Pressure
  • Pilot Membrane Structure
  • AC Solenoid Valve
  • Flow Control
  • DIN
  • Industrial Usage, Water Industrial Usage, Household Usage
  • 12VDC, 24VDC, 110VAC, 220VAC
  • XHnotion
  • Paper Box
  • ROHS, REACH, CE
  • China
  • 8481804090
  • Gas
  • High Temperature
  • Electric
  • Thread
  • Pilot Operated
  • Brass
Product Description
FEATURE:
1. High temperature solenoid valve
2. Seal material: PTFE, Viton seal option;
3. Medium: Steam, hot oil;
4. Max medium temp.: 180 degree celsius. One model can reach 250 degree celsius.
5. Pipe Size: 1/8-2
6. Flange connection: 25-150F.


SPECIFICATION:
MODEL Orifice Pipe Thread Working pressure Environment Temp. Medium Temp. CV value Voltage
(mm) (G) (Bar) (Celsius) (Celsius)
ZQDF-15 15 G1/2 0-8 -10~55 -5-180 3.7 220VAC/50HZ 110VAC/50HZ 24VDC
ZQDF-20 20 G3/4 7
ZQDF-25 25 G1 11
ZQDF-32 32 G1-1/4 14
ZQDF-40 40 G1-1/2 24.5
ZQDF-50 50 G2 35
ZQDF-25F 15 Flange 4 holes, holes diameter: 13.5mm holes distance: 85mm 11
ZQDF-32F 32 Flange 4 holes, holes diameter: 17.5mm holes distance: 100mm 14
ZQDF-40F 40 Flange 4 holes, holes diameter: 17.5mm holes distance: 110mm 24.5
ZQDF-50F 50 Flange 4 holes, holes diameter: 17.5mm holes distance: 125mm 35
ZQDF-15B 15 G1/2 3.7
ZQDF-20B 20 G3/4 7
ZQDF-25B 25 G1 11
ZQDF-32B 32 G1-1/4 14
ZQDF-40B 40 G1-1/2 24.5
ZQDF-50B 50 G2 35
ZQDF-25FB 25 Flange 4 holes, holes diameter: 13.5mm holes distance: 85mm 11
ZQDF-32FB 32 Flange 4 holes, holes diameter: 17.5mm holes distance: 100mm 14
ZQDF-40FB 40 Flange 4 holes, holes diameter: 17.5mm holes distance: 110mm 24.5
ZQDF-50FB 50 Flange 4 holes, holes diameter: 17.5mm holes distance: 125mm 35


ADVANTAGE

1) Raw Material conforms to China industry standard, bought from famous factory.

2) Insulation grade: H class, good resistance to high temperature;

3) Machined by CNC to make sure the tolerance as the drawing

4) 100% leakage testing under low pressure and high pressure.

5) All kinds of valve and seals material to meet custom requirement.

6) 1 year quality assurance after shipment.

7) After sales technique support


WORKSHOP SHOW
WHY CHOOSE US?

1) We offer one stop solution. Over 5000 items for you to save efforts and costs.

2)We have molds workshop, die-casting workshop, CNC workshop, plastic injection workshop to make sure each part exactly as the drawing and good function.

3) We will reply you within 24 hours.

4) Whatever quantity you are requesting, we always offer you the best quality.

5)3D drawing, cad drawing service for custom fittings, hose, valve, cylinder





FAQ

Packing
Transparent plastic bag + white small box + neutral carton + pallet
Custom packaging are available, XHnotion brand packaging are available

Shipping :
Export port: Ningbo or Shanghai, China
Shipping way: by sea, by air, by courier
Delivery time 3 days to 30 days depends on actual orders.

Payment Terms
We accept T/T, L/C, Paypal, western union,etc.

Samples Policy
For regular fittings below 20 pcs, free samples against your courier account or you pick up from us.
For custom items, we will discuss by email.

Return Policy:
We assure you 1 year policy after shipment. If there is any problem during this period, please contact us for support.


============================================================
We have thousands of solenoid valve in the stock. If you do not know how to order our valve, please tell us some necessary information, we will recommend you the most economical solenoid valve.

1. valve material
2. working pressure
3. temperature range
4 working environment
5. quantity

You can choose as below

Body Material: Plastic, brass, SS304, SS306, Steel.
Seal Material: NBR, VITON, PTFE, EPDM, SILICONE
Voltage: 12VDC, 24VDC, 24VAC, 220VAC, 280VAC
Size: M5-2", Flange connection


==========================================================
