| Quantity: | |
|---|---|
PA12
L/C, T/T, Paypal, Money Gram, Western Union
1000000 meter per month
box or spool
PA12
2-12mm
8-70mm
100m,200m
XHnotion
ROHS, REACH, CE
China
3917290000
TPU, Nylon, LDPE
GB, DIN
3-40mm
Compressed Air
Round
Thread
| Technical Information | Nylon Tubing (Polyamide Tube) | |||||||||||||||||||||||||||||||||||||||||||||||
| Material | PA12, PA11, PA6 | |||||||||||||||||||||||||||||||||||||||||||||||
| Fluid | Air, Water, Oil | |||||||||||||||||||||||||||||||||||||||||||||||
| Burst Pressure ( 20 oC) | 870 Psi | |||||||||||||||||||||||||||||||||||||||||||||||
| Working Pressure ( 20 oC) | 0-360 Psi | |||||||||||||||||||||||||||||||||||||||||||||||
| Operating Temperature | -40~120 ℃ | |||||||||||||||||||||||||||||||||||||||||||||||
| Density | 1.04 g/cc | |||||||||||||||||||||||||||||||||||||||||||||||
| Size Tolerance | 3-8mm, +/-0.10 mm | |||||||||||||||||||||||||||||||||||||||||||||||
| 10-20mm, +/-0.15 mm | ||||||||||||||||||||||||||||||||||||||||||||||||
| Metric Size | O.D.(mm) | I.D.(mm) | Bending Radius(mm) | Standard Length |
| NY0320 | 3 | 2 | 18 | 100m |
| NY0425 | 4 | 2.5 | 20 | 100m |
| NY0640 | 6 | 4 | 40 | 100m |
| NY0860 | 8 | 6 | 50 | 100m |
| NY1075 | 10 | 7.5 | 65 | 100m |
| NY1080 | 10 | 8 | 65 | 100m |
| NY1290 | 12 | 9 | 70 | 100m |
| NY1411 | 14 | 11 | 80 | 100m |
| NY1612 | 16 | 12 | 130 | 100m |
| NY1815 | 18 | 15 | 155 | 100m |
| Imperial Size | O.D.(Inch) | I.D.(Inch) | Bending Radius(mm) | Standard Length |
| NY1/8 | 1/8" | 0.079" | 18 | 100m |
| NY5/32 | 5/32" | 0.093" | 20 | 100m |
| NY1/4 | 1/4" | 0.17" | 40 | 100m |
| NY5/16 | 5/16" | 0.236" | 50 | 100m |
| NY3/8 | 3/8" | 0.295" | 65 | 100m |
| NY1/2 | 1/2" | 0.355" | 70 | 100m |
| NY1/2 | 1/2" | 0.33" | 35 | 100m |
Packing
neutral carton + big carton
Custom packaging are available, XHnotion brand packaging are available
Shipping :
Export port: Ningbo or Shanghai, China
Shipping way: by sea, by air, by courier
Delivery time 3 days to 30 days depends on actual orders.
Payment Terms
We accept T/T, L/C, Paypal, western union,etc.
Samples Policy
Free samples against your courier account or you pick up from us.
For custom items, we will discuss by email.
Return Policy:
We assure you 1 year policy after shipment. If there is any problem during this period, please contact us for support.
