Features
The entire range is top quality, heavy-duty and reliable.
These units are designed for use at high pressures and in applications where the temperature and quality of the ambient area are critical.
Heavy duty and reliable piston-operated FR+L unit.
1.Stability of the set pressure as the upstream pressure varies
2.Metal bowl with external sight glass
3.Semi-automatic and automatic condensate drain
4.Quantity of lubricant proportioned to air flow
5.Micrometric lubrication regulation
6.Activation guaranteed with low flow rates
SPECIFICATIONS
| Type | MAC100-M5,01 | MAC200-01,02,03 | MAC400-03,04,06 | MAC600-06,08 |
| Port Size | M51/8 | 1/8,1/4,3/8 | 3/8,1/2,3/4 | 3/4,1 |
| Gauge thread G | M5 | M1/8 | M1/4 | |
| Fluid | Compressed Air | |||
| Operating pressure range MPa | 0.15-0.85 | 0.15-1.2 | ||
| Max.Flow rate L/min | 500 | 1700 | 3500 | 11500 |
| Ambient temperture ºC | -10-60 | |||
| Filter precision | 5um or 40um | |||
| Structure | Overflow type | |||
| Guard cup | - | Yes | Yes | Yes |
AIR PREPARATION UNIT ADVANTAGE
1) We source good raw material to protect environment. Threads are machined by CNC to promise smooth and accurate, no blurs.
2) O-ring is imported from Taiwan.
3) 5-40 um filter is available. Rich stock for regular models.
5) 100% leakage testing under low pressure and high pressure.
6) 1 year quality assurance after shipment.
7) After sales technique support
