Pneumatic Air Source Treatment Unit

Quantity:
  • 20 Pieces
  • Ningbo, China
  • 10000 PCS Per Month
  • L/C, T/T, Western Union, Paypal, Money Gram
  • HNAW4000-04
  • M5, 1/8, 1/4, 3/8, 1/2, 3/4, 1
  • Pneumatic Filter
  • New
  • XHnotion
  • Carton
  • 1000-5000
  • China
  • 8421999000
  • Non-Customized
  • Xhnotion
  • Normal Temperature
  • Aluminum
  • 25um
  • 1/16, 1/8, 1/4
Product Description
FEATURES
1. Compact and light weight.

2. Flow rate is 20% higher than that of traditional ones(Max. Flow Rate:1 l/min).

3. Exhaust rate is 5 time than that of traditional ones.

4. Precise pressure setting.

5.Easy for mounting,capable of mounting individually, together with modular filter combination and mounting on panel.

6. Piloted exhaust and main exhaust are separated.

7. Applicable for clean room.



SPECIFICATIONS
Ensured Pressure Resistance 1.5MPa(15kgf/cm²)
Highest Working Pressure 1.0MPa(10kgf/cm²)
Ambient and Fluid Temperature 5-60ºC
*Filter Precision 25um
Recommended Oil Use Turbine No.1 Oil ISOCG32
Container Material Polycarbonate
Protective Cover HNAW1000-2000(Not Available)HNAW2500-5000(Available)
Pressure Regulating Range HNAW1000:0.05-0.7MPa(0.5-7kgf/cm²)
HNAW2000-5000:0.05-0.85MPa(0.5-8.5kgf/cm²)
Valve Type With Overflow




Model Specification Bracket Drain Function Auto Drain Model
Flow Rate*
(L/min)
SCFM* Cubic Feet /min Port Size Pressure Gauge size
(G)
Weight(Kg)
HWAW1000-M5 110 3.5 M5 1/16 0.09 B120 Manual Drain -
HWAW2000-01 550 19.4 1/8" 1/8 0.36 B220 HNAW2000-01D
HWAW2000-02 1/4" HNAW2000-02D
HWAW3000-02 2000 70.6 1/4" 1/8 0.56 B320 a.Air Shutoff Drain





b.Manual Drain
HNAW3000-02D
HNAW3000--03 3/8" HNAW3000--03D
HNAW4000-03 4000 141 3/8" 1/4 1.15 B420 HNAW4000-03D
HNAW4000-04 1/2" HNAW4000-04D
HNAW4000-06 4500 159 3/4" 1/4 1.21 HNAW4000-06D
HNAW5000-06 5500 194 3/4" 1/4 1.70 HNAW5000-06D
HNAW5000-10 1 HNAW5000-10D



AIR PREPARATION UNIT ADVANTAGE

1) We source good raw material to protect environment. Threads are machined by CNC to promise smooth and accurate, no blurs.

2) O-ring is imported from Taiwan.

3) 5-40 um filter is available. Rich stock for regular models.

5) 100% leakage testing under low pressure and high pressure.

6) 1 year quality assurance after shipment.

7) After sales technique support



WHY CHOOSE US?

1)XHnotion offer one stop solution. Over 5000 items for you to save efforts and costs.

2)We have molds workshop, die-casting workshop, CNC workshop, plastic injection workshop to make sure each part exactly as the drawing and good function.

3) We will reply you within 24 hours.

4) Whatever quantity you are requesting, we always offer you the best quality.

5)3D drawing, cad drawing service for custom fittings, hose, valve, cylinder








==========================================================
XHnotion, is a leading manufacturer of pneumatic components and fluid valve in China. Our air preparation unit include below series.

DC series FRL unit
AC series FRL unit
HAC series FRL unit
HNAC series FRL unit
AC/BC series FRL unit
39 series FRL unit
High pressure FRL unit
Precision regulator

FRL unit Is consist of air filter, air lubricator, air regulator, gauge, auto drain, two-unit modular combinations, three unit modular combinations, filter regulator.


Meanwhile, we also manufacture below items.


pneumatic fittings, plastic, brass, stainless steel push in fittings

pneumatic quick coupling, air tool kits, air blow gun

pneumatic muffler, silencer, filter

air hose- PU tubes, nylon tube, PE tube, PTFE tubes, etc

air cylinder, 2 way solenoid valve, directional pneumatic valve

modular hose, water push in fitting

Ball valve, brass connector

=========================================================
FAQ

Packing
Transparent plastic bag + neutral carton + neutral box + pallet
Custom packaging are available, XHnotion brand packaging are available

Shipping :
Export port: Ningbo or Shanghai, China
Shipping way: by sea, by air, by courier
Delivery time 3 days to 30 days depends on actual orders.

Payment Terms
We accept T/T, L/C, Paypal, western union,etc.

Samples Policy
For regular item1 piece, free samples against your courier account or you pick up from us.
For custom items, we will discuss by email.

Return Policy:
We assure you 1 year policy after shipment. If there is any problem during this period, please contact us for support.
