| Quantity: | |
|---|---|
L/C, T/T, Paypal, Money Gram, Western Union
10000m Per Month
Box or Spool
PU1/8
Air, Water
2-12mm
8-70mm
100m,200m
XHnotion
ROHS, REACH, CE
China
3917290000
PU
GB, DIN
3-40mm
Compressor Air
Round
Barb
| Technical Information | Polyurethane Tubing |
| Material | Polyester (Polyether option) |
| Fluid | Air, Water |
| Burst Pressure ( 20oC) | 400 Psi |
| Working Pressure ( 20oC) | 0-150 Psi |
| Operating Temperature | -20~60 ºC |
| Shore | 95A, 98A |
| Size Tolerance | 3-8mm, +/-0.10 mm |
| 10-16mm, +/-0.15 mm |
| Metric Size | O.D.(mm) | I.D.(mm) | Bending Radius(mm) | Standard Length |
| PU0320 | 3 | 2 | 8 | 200m |
| PU0425 | 4 | 2.5 | 10 | 200m |
| PU0530 | 5 | 3 | 10 | 200m |
| PU0640 | 6 | 4 | 15 | 200m |
| PU0860 | 8 | 6 | 20 | 100m |
| PU0850 | 8 | 5 | 20 | 100m |
| PU1065 | 10 | 6.5 | 25 | 100m |
| PU1280 | 12 | 8 | 35 | 100m |
| PU1410 | 14 | 10 | 45 | 100m |
| PU1612 | 16 | 12 | 70 | 100m |
| Imperial Size | O.D.(Inch) | I.D.(Inch) | Bending Radius(mm) | Standard Length |
| PU1/8 | 1/8" | 0.079" | 8 | 200m |
| PU5/32 | 5/32" | 0.093" | 10 | 200m |
| PU3/16 | 3/16" | 1/8" | 10 | 200m |
| PU1/4 | 1/4" | 0.17" | 15 | 100m |
| PU5/16 | 5/16" | 0.196" | 20 | 100m |
| PU3/8 | 3/8" | 1/4" | 25 | 100m |
| PU1/2 | 1/2" | 0.33" | 35 | 100m |
