Ba Series Pneumatic Angle Valve

Model NO.: BA4010Open Manner: Quick-OpeningSize: 0.5Usage: Heating PipelineSituation: IndustrialService Life: >3 YearsActuator Material: PA66Acting Way: 2 Way 2 PositionTrademark: XHnotionTransport Package: Paper BoxSpecification: ROHS, REACH, CEOrigin: ChinaHS Code: 8481804090Temperature: Ordinary TemperatureMedia: GasMaterial: Stainless SteelStandard: ISO9001Valve Plug: Rubber RingConnection Form: Thread
Availability:
Quantity:
  • BA4010

  • XHNOTION

  • L/C, T/T, Western Union, Paypal, Money Gram

  • Ningbo, China

  • 10000 PCS Per Month

  • CARTONS

  • BA4010

  • Quick-Opening

  • 0.5

  • Heating Pipeline

  • Industrial

  • >3 Years

  • PA66

  • 2 Way 2 Position

  • XHnotion

  • Paper Box

  • ROHS, REACH, CE

  • China

  • 8481804090

  • Ordinary Temperature

  • Gas

  • Stainless Steel

  • ISO9001

  • Rubber Ring

  • Thread

Product Description

FEATURES

1. Y-shape enlarge the flowing section, which raise the flow more by 30%.

2. Valve stem is SS316L material, with strong anti-corrosive ability. PTFE seals with wedge shape helps the stem adjust automatically and maintaince free.

3. Actuator material: PA and SS304.

4.  Valve body material: brass, SS304, SS316

5. Control medium: neutral air, Controlling pressure: 3-8 bar.

6.  Fluid pressure: Max 16 bar.

7. Fluid Temperature: -10~180ºC.

8. Working type:  Double acting,  Single acting.


SPECIFICATIONS

Specifications for BA Normally Closed

Model Actuator Orifice CV Value Pipe Thread Working pressure Control Pressure Medium Temp.
Double acting Single Acting mm mm m3/h G Mpa Mpa ºC
BA4010-40 BA5010-40 40 13 4.7 3/8" 0-1.6 0.3~0.8 -10~180ºC
BA4010-50 BA5010-50 50 13 4.7 3/8"
BA4015-40 BA5015-40 40 13 4.7 1/2"
BA4015-50 BA5015-50 50 13 4.7 1/2"
BA4020-50 BA5020-50 50 20 9.5 3/4"
BA4025-50 BA5025-50 50 25 22 1"
BA4025-63 BA5025-63 63 25 22 1"
BA4032-63 BA5032-63 63 32 32 1-1/4"
BA4032-80 BA5032-80 80 32 32 1-1/4"
BA4040-63 BA5040-63 63 40 41 1-1/2"
BA4040-80 BA5040-80 80 40 41 1-1/2"
BA4050-63 BA5050-63 63 50 57 2"
BA4050-80 BA5050-80 80 50 57 2"


Specification for BA Series Normally Open


Model Actuator Orifice CV Value Pipe Thread Working pressure Control Pressure Medium Temp.
Double acting Single Acting mm mm m3/h G Mpa Mpa ºC
KBA4010-50 KBA5010-50 50 13 4.7 3/8" 0-1 0.4~0.6 -10~180ºC
KBA4015-50 KBA5015-50 50 13 4.7 1/2"
KBA4020-50 KBA5020-50 50 20 9.5 3/4"
KBA4025-63 KBA5025-63 63 25 22 1"
KBA4032-80 KBA5032-80 80 32 32 1-1/4"
KBA4040-80 KBA5040-80 80 40 41 1-1/2"
KBA4050-100 KBA5050-100 100 50 57 2"




ADVANTAGE


1) Raw Material conforms to China industry standard, bought from famous factory.

2) Insulation grade: H class, good resistance to high temperature;

3) Machined by CNC to make sure the tolerance as the drawing

4) 100% leakage testing under low pressure and high pressure.

5) All kinds of valve and seals material to meet custom requirement.

6) 1 year quality assurance after shipment.

7) After sales technique support



WHY CHOOSE US?

1) We offer one stop solution. Over 5000 items for you to save efforts and costs.

2)We have molds workshop, die-casting workshop, CNC workshop, plastic injection workshop to make sure each part exactly as the drawing and good function.

3) We will reply you within 24 hours.

4) Whatever quantity you are requesting, we always offer you the best quality.

5)3D drawing, cad drawing service for custom fittings, hose, valve, cylinder





FAQ

Packing
Transparent plastic bag + white small box + neutral carton + pallet
Custom packaging are available, XHnotion brand packaging are available

Shipping :
Export port: Ningbo or Shanghai, China
Shipping way: by sea, by air, by courier
Delivery time 3 days to 30 days depends on actual orders.

Payment Terms
We accept T/T, L/C, Paypal, western union,etc.

Samples Policy
For regular fittings below 20 pcs, free samples against your courier account or you pick up from us.
For custom items, we will discuss by email.

Return Policy:
We assure you 1 year policy after shipment. If there is any problem during this period, please contact us for support.



==========================================================
XHnotion, is a leading manufacturer of pneumatic components and fluid valve in China. Our solenoid valve include below items

Fluid assortment

Water solenoid valve
Air solenoid valve
Diesel solenoid valve
Chemical solenoid valve
We have different solenoid valve for different fluid


Structure assortment

2 way solenoid valve
3 way solenoid valve
4 way solenoid valve
5 way solenoid valve


Acting assortment

Direct acting solenoid valve
Pilot acting solenoid valve


Function assortment

common solenoid valve for air, water
High pressure solenoid valve
Steam solenoid valve
Irrigation solenoid valve
Underwater solenoid valve
Drinking water solenoid valve
Auto drain solenoid valve
Pneumatic angle valve
Pulse jet solenoid valve
Bi-stable solenoid valve
Throttle solenoid valve
Miniature steam solenoid valve




Material assortment

Brass solenoid valve
Plastic solenoid valve
Stainless steel solenoid valve
PTFE solenoid valve
PVC solenoid valve
POM solenoid valve

Meanwhile, we also manufacture below items.


pneumatic fittings, plastic, brass, stainless steel push in fittings

pneumatic quick coupling, air tool kits, air blow gun

pneumatic muffler, silencer, filter

air hose- PU tubes, nylon tube, PE tube, PTFE tubes, etc

air cylinder, air preparation, pneumatic directional valve

modular hose, water push in fitting

Ball valve, brass connector
