| Quantity: | |
|---|---|
UPB
XHNOTION
L/C, T/T, Western Union, Paypal, Money Gram
Ningbo, China
100000 PCS Per Day
PLASTIC BAG AND CARTON
UPB
3mm-16mm
Hexagon
Male
M5, M6, 1/8, 1/4, 3/8, 1/2
Nickel-Plated
Ce, RoHS, TUV
Plastic Bag
China
7412209000
Quick Connector
Air Compressor, Air Line
Xhnotion
Normal Temperature
Brass
DIN, GB
Features
1. Used for pneumatic soft tube. PU tubes are the best choice.
2. Working pressure depends on tube pressure.
3. BSPT, BSPP, NPT and Metric thread are available.
4. Spring sleeve type and swivel type are available.
Material Construction
| Metal Body | Nickel Plated Brass or Brass |
| Release Button | Nickel Plated Brass or Brass |
| Thread Sealant | Teflon |
| O-Ring | NBR or Viton |
Specifications
| Operating Pressure | 0~20 bar |
| Operating Temperature | -10 ~ 60°C |
| Application | Water, Air, Oil, Diesel, and other fluids. |
| Recommended Tubing Material | Polyurethane, Nylon, Polyenthylee, and Polypropylene |
| Types | Straight |
| Capacity | Over 1000000pcs/month |
| Marketing Area | All over the world |
Fitting Advantage
1. Raw Material is HPB 59-1, conforms to country standard.
2. High precision automatic lathe to make the claws not hurt tube surface.
3. 5% tested by water at 10 bar, 100% tested by air and appearance test.
4. Easy to push in and put out on the basis of working pressure assured
5. 1 year quality assurance after shipment.
6. Custom fitting as your drawing or we make drawing as your sample.
