2N Series Stainless Steel Solenoid Valve

Quantity:
  • Ningbo, China
  • 10000 PCS Per Month
  • L/C, T/T, Western Union, Paypal, Money Gram
  • 2N050-08B
  • Ordinary Pressure
  • Direct Action Diaphragm Structure
  • DC Solenoid Valve
  • Flow Control
  • DIN
  • Industrial Usage, Water Industrial Usage
  • 12VDC, 24VDC, 110VAC, 220VAC
  • Air, Water, Oil, Diesel, Ozone, Steam
  • XHnotion
  • Paper Box
  • ROHS, REACH, CE
  • China
  • 8481804090
  • Water
  • Ordinary Temperature
  • Electric
  • Thread
  • Direct Acting
  • Stainless Steel
Product Description
FEATURES

1. Compact volume, large flow, widely use

2. Protection class: IP65, dust proof and water proof, can be used for outdoors

3. DIN connector and wire leads are available

4. Insulation grade: H class, good resistance to high temperature;

5. NBR, VITON, EPDM, SILICONE seals are available

6. Normally closed and normally open





SPECIFICATIONS

Specification for 2N Series Normally Closed Solenoid Valve
Model Thread Size (G) Orifice (mm) CV Working Pressure (Bar) Seals Voltage
AC DC
Brass body Stainless steel air, gas water ≤20cst oil air, gas water ≤20cst oil
2N030-06 2N030-06B 1/8" 3 0.3 0-10 0-10 0-7 0-7 0-7 0-5 NBR seals ≤80ºC; Viton seals ≤150ºC; EPDM seals ≤120ºC Silicone seals ≤100ºC 220VAC 110VAC 24VDC 12VDC make Other voltage as requested
2N030-08 2N030-08B 1/4" 3 0.3 0-10 0-10 0-7 0-7 0-7 0-5
2N040-08 2N040-08B 1/4" 4 0.58 0-5 0-5 0-4 0-4 0-4 0-3
2N050-08 2N050-08B 1/4" 5 0.65 0-4 0-4 0-3 0-3 0-3 0-2
2N060-08 2N060-08B 1/4" 6 0.8 0-10 0-10 0-10 0-7 0-7 0-7
2N150-10 2N150-10B 3/8" 15 4.6 0-10 0-10 0-10 0-7 0-7 0-7
2N150-15 2N150-15B 1/2" 15 4.6 0-10 0-10 0-10 0-7 0-7 0-7
2N200-20 2N200-20B 3/4" 20 8.5 0-10 0-10 0-10 0-7 0-7 0-7
2N250-25 2N250-25B 1" 25 12 0-10 0-10 0-10 0-7 0-7 0-7
2N320-35 2N320-35B 1 1/4" 32 24 0-10 0-10 0-10 0-7 0-7 0-7
2N400-40 2N400-40B 1 1/2" 40 29 0-10 0-10 0-10 0-7 0-7 0-7
2N500-50 2N500-50B 2" 50 48 0-7 0-7 0-7 0-5 0-5 0-5
2N250-25F 2N250-25FB 4 holes flange 25 12 0-10 0-10 0-10 0-7 0-7 0-7
2N320-35F 2N320-35FB 32 24 0-10 0-10 0-10 0-7 0-7 0-7
2N400-40F 2N400-40FB 40 29 0-10 0-10 0-10 0-7 0-7 0-7
2N500-50F 2N500-50FB 50 48 0-7 0-7 0-7 0-5 0-5 0-5

Specification for 2N Series Normally Open Solenoid Valve
Model Thread Size (G) Orifice (mm) CV Working Pressure (Bar) Seals Voltage
AC DC
Brass body Stainless steel air, gas water ≤20cst oil air, gas water ≤20cst oil
2N030-06H 2N030-06BH 1/8" 3 0.3 0-7 0-7 0-6 0-6 0-6 0-4 NBR seals ≤80 ºC Viton seals ≤150ºC EPDM seals ≤120ºC Silicone seals ≤100ºC 220VAC 110VAC 24VDC 12VDC make Other voltage as requested
2N030-08H 2N030-08BH 1/4" 3 0.3 0-7 0-7 0-6 0-6 0-6 0-4
2N040-08H 2N040-08BH 1/4" 4 0.58 0-4 0-4 0-3 0-3 0-3 0-2
2N050-08H 2N050-08BH 1/4" 5 0.65 0-3 0-3 0-2 0-2 0-2 0-1
2N060-08H 2N060-08BH 1/4" 6 0.8 0-5 0-5 0-3 0-3 0-3 0-3
2N150-10H 2N150-10BH 3/8" 15 4.6 0-5 0-5 0-3 0-3 0-3 0-3
2N150-15H 2N150-15BH 1/2" 15 4.6 0-5 0-5 0-3 0-3 0-3 0-3
2N200-20H 2N200-20BH 3/4" 20 8.5 0-5 0-5 0-3 0-3 0-3 0-3
2N250-25H 2N250-25BH 1" 25 12 0-5 0-5 0-3 0-3 0-3 0-3
2N320-35H 2N320-35BH 1 1/4" 32 24 0-5 0-5 0-3 0-3 0-3 0-3
2N400-40H 2N400-40BH 1 1/2" 40 29 0-5 0-5 0-3 0-3 0-3 0-3
2N500-50H 2N500-50BH 2" 50 48 0-5 0-5 0-3 0-3 0-3 0-3
2N250-25FH 2N250-25FBH 4 holes flange 12 0-5 0-5 0-3 0-3 0-3 0-3
2N320-35FH 2N320-35FBH 32 24 0-5 0-5 0-3 0-3 0-3 0-3
2N400-40FH 2N400-40FBH 40 29 0-5 0-5 0-3 0-3 0-3 0-3
2N500-50FH 2N500-50FBH 50 48 0-5 0-5 0-3 0-3 0-3 0-3





ADVANTAGE

1) Raw Material conforms to China industry standard, bought from famous factory.

2) Insulation grade: H class, good resistance to high temperature;

3) Machined by CNC to make sure the tolerance as the drawing

4) 100% leakage testing under low pressure and high pressure.

5) All kinds of valve and seals material to meet custom requirement.

6) 1 year quality assurance after shipment.

7) After sales technique support


WHY CHOOSE US?

1) We offer one stop solution. Over 5000 items for you to save efforts and costs.

2)We have molds workshop, die-casting workshop, CNC workshop, plastic injection workshop to make sure each part exactly as the drawing and good function.

3) We will reply you within 24 hours.

4) Whatever quantity you are requesting, we always offer you the best quality.

5)3D drawing, cad drawing service for custom fittings, hose, valve, cylinder





FAQ

Packing
Transparent plastic bag + white small box + neutral carton + pallet
Custom packaging are available, XHnotion brand packaging are available

Shipping :
Export port: Ningbo or Shanghai, China
Shipping way: by sea, by air, by courier
Delivery time 3 days to 30 days depends on actual orders.

Payment Terms
We accept T/T, L/C, Paypal, western union,etc.

Samples Policy
For regular fittings below 20 pcs, free samples against your courier account or you pick up from us.
For custom items, we will discuss by email.

Return Policy:
We assure you 1 year policy after shipment. If there is any problem during this period, please contact us for support.


============================================================
We have thousands of solenoid valve in the stock. If you do not know how to order our valve, please tell us some necessary information, we will recommend you the most economical solenoid valve.

1. valve material
2. working pressure
3. temperature range
4 working environment
5. quantity

You can choose as below

Body Material: Plastic, brass, SS304, SS306, Steel.
Seal Material: NBR, VITON, PTFE, EPDM, SILICONE
Voltage: 12VDC, 24VDC, 24VAC, 220VAC, 280VAC
Size: M5-2", Flange connection
