1) 1/4" brass industrial coupler - 1/4"-18NPTF, (1) 1/4" brass industrial coupler - 1/4"-18NPTM, (2) 1/4" brass industrial plugs 1/4"-18NPTF, (2) 1/4" brass industrial plugs 1/4"-18NPTM, (1) brass female ball foot tire chuck, (1) inflation needle, (1) blow gun, (1) safety nozzle, (1) rubber tip, (1) tapered inflation nozzle
Used for pneumatic systems;
|Material ||Brass or Steel |
|Working Pressure ||0-145PSI |
|1/4" brass industrial coupler ||1/4"-18NPTF, 1PC |
|1/4" brass industrial coupler ||1/4"-18NPTM, 1PC |
|1/4" brass industrial plugs ||1/4"-18NPTF, 2PCS |
|1/4" brass industrial plugs ||1/4"-18NPTM, 2PCS |
|brass female ball foot tire chuck ||1PC |
|inflation needle ||1PC |
| blow gun ||1PC |
|safety nozzle ||1PC |
|rubber tip ||1PC |
|tapered inflation nozzle ||1PC |
Working pressure: Less than 145 Psi;
Brass and steel are both available;
XHNOTION can produce quick coupler, air coupling etc.
XHNOTION can also make other standards quick couplers according to customer requirements, such as Australia quick coupling, Italy quick coupling, Germany quick coupling, England quick coupling, Milton coupler, ARO coupler, Industrial Interchange, Tru-flate Interchange, Lincoln Interchange, Asia Type Interchange, Schrader Interchange, Israel coupler.
Quick couplers has one touch quick coupler and two touch quick coupler; As material, there are steel quick coupler, brass quick coupler, stainless steel quick coupler, aluminum quick coupler. Coupler has two parts, one is socket, the other is plug, socket is usually check valve.
XHNOTION quick coupler can be used for air tools, air compressors, air blow gun, spray gun. So it's also called air tools kits, air tools couplers, air tools accessories, pneumatic tools coupler, air tools coupling, air compressor accessories, air compressor kits, air compressor coupler,
Quick coupler specification
1. Max pressure: 150 Psi
2. Temperature range: -20~70 Celsius degree
3. Air flow: 35 SCFM at 100 PSIG inlet with 10 PSIG pressure dro
